SHINING 3D, a developer and provider of professional 3D digitizing and metrology solutions, launches the FreeScan Trak ProW+, the upgraded successor to the FreeScan Trak ProW.
Designed for efficient measurement of large-scale workpieces, the new wireless 3D dynamic tracking and scanning system delivers an ultra-large tracking range, marker-free scanning, and greater freedom of movement, helping manufacturers streamline large-object inspection.
Tracking range and scanning speed
The FreeScan Trak ProW+ features an ultra-long tracking distance of up to 8.6 meters and expands the single-station tracking volume to 156 m³. By covering a larger area from a single tracker position, it significantly reduces the need for leapfrog operations during large-scale scanning. As a result, users can improve measurement efficiency and simplify workflows.
The system also retains the core advantages of the FreeScan Trak Pro series, including high accuracy, stable repeatability, and rapid data acquisition. Scanning speeds reach up to 7.6 million points per second. Users can therefore capture large amounts of 3D data quickly, without the time-consuming placement of markers.
Multiple laser modes include 93 crossed laser lines, 25 parallel laser lines, and a single laser line. These support both high-speed scanning and detailed measurement of complex or hard-to-reach features.
Wireless operation and volumetric accuracy
With integrated computing and wireless modules, the FreeScan Trak ProW+ provides a truly cable-free scanning experience. It combines real-time data processing with stable wireless transmission. A built-in display provides convenient access to key device information. This gives operators greater freedom to move around large workpieces and work efficiently in demanding shop-floor environments.
For large-scale applications requiring volumetric accuracy, SHINING 3D offers its patented Video Photogrammetry (VPG) technology. Video capture and a calibration rod enable real-time marker verification without coded markers. This streamlines setup and supports consistent measurement accuracy across large volumes.
For extremely large objects, multiple FreeScan Trak ProW+ systems can also work together to expand measurement coverage. This offers a flexible solution for full-field scanning.
